Home > Prodotti > Strumenti da processo > Regolatori > Panel-mounted ORP Analog Indicator with Self Diagnostic Test – HI8512

SKU: HI8512

Panel-mounted ORP Analog Indicator with Self Diagnostic Test – HI8512

570,00 + IVA

10048 disponibili (ordinabile)

Acquista & guadagna 570 punti!
Richiedi informazioni

HI8512 ORP panel mounted controller is ideal for process control monitoring in a wide range of industrial applications. This instrument has been designed for easy and fast installation, and is provided with membrane keypads on the front panel, large display, and auto-diagnostic functions.

  • Auto-diagnostic tests for electrode and instrument status.
  • Displays values on the easy to read LCD.
  • A removable, transparent splash-proof cover protects the front panel.
Tempi di spedizione
Non a stock, spedizione prevista entro 10 giorni lavorativi
Garanzia diretta dal produttore
Assistenza clienti sempre a disposizione
Maggiori informazioni
Specifiche tecniche
Recensioni
Downloads
Info Ordine

Self-testing Diagnostics

Built-in auto-diagnostic functions to enable the user to check and troubleshoot any malfunctions. The functions are made via front panel keys to isolate the cause of malfunction whether it is due to pH electrode contamination, internal offset circuit or the amplifier circuit.

Recorder Terminals

To enhance troubleshooting and the ability to record data while monitoring, simply attach a recording device to the instrument’s 4 to 20 mA output contacts, conveniently located on the front panel, to obtain a copy of the results on demand.

Easy Installation

HI8512 is provided with membrane keypads on the front panel, large display, and auto-diagnostic functions to check pH electrode and instrument status.

Easy pH Electrode Connection

Allows for quick and easy connection to any ORP meter or transmitter.

Protective Cover

A removable, transparent splash-proof cover protects the front panel.

LED Indicators

LED indicators identify the controller mode.

Scala ORP: ±1000 mV
Risoluzione ORP: 1 mV
Accuratezza ORP: ± % 5 mV (electrode); ± 0.5% (transmitter)
Calibrazione mV (ORP): Offset: ±200 mV with CAL trimmer
Segnale Ingresso Analogico: 4 to 20 mA
Segnale Uscita Analogica: 0-20 mA or 4-20 mA (isolated)
Retroilluminazione: Continuous ON
Voltaggio di Uscita: ±5 Vcc; 150 mA max load for amplified electrodes
Componenti Esterne Incluse: Black anodized aluminium body; front and back with ABS; transparent splash-proof front cover
Alimentatore: 115 or 230 Vac; 60/50 Hz
Condizioni di Utilizzo: -10 to 50°C (14 to 122°F); RH max 95% non-condensing
Dimensioni: 141 x 69 mm (5.6 x 2.7'')
Peso: 1 kg (2.2 lb.)

Non ci sono download disponibili per questo prodotto
Non ci sono informazioni sull'ordine di questo prodotto
